    RGH Display 1.83 Inch IPS TFT LCD Display Module 240x284 Home Appliance With ST7789P3-G6 Interface

    Ask Lasest Price
    Brand Name : RGH
    Model Number : RTP183001A
    Certification : ISO9001/ISO14001
    Price : Negotiable
    Payment Terms : L/C, T/T,Paypal
    Supply Ability : 3.5kk
    Delivery Time : 3-5weeks
    • Product Details
    • Company Profile

    RGH Display 1.83 Inch IPS TFT LCD Display Module 240x284 Home Appliance With ST7789P3-G6 Interface

    1.83 Inch IPS TFT LCD Display Module 240x284 Home Appliance


    ItemSpecification

    Size

    1.83 inch

    Display mode

    Transmissive TFT

    Part NO.

    RTP183001A

    Resolution

    240*248

    Outline size

    46.6 (H) X45.2(V) X2.86(T)

    Active area

    29.52(H) X34.93 (V)

    View direction

    ALL o’clock

    Piexl pitch

    240X(RGB)X 284

    Interface

    SPI

    Backlight

    3LEDS

    Surface luminance

    400cd/m2

    Logic voltage

    2.5V-3.3V

    Operating temperature

    -10℃~60℃

    Storage temperature

    -20℃~70℃

    RGH Display 1.83 Inch IPS TFT LCD Display Module 240x284 Home Appliance With ST7789P3-G6 Interface

    RGH Display 1.83 Inch IPS TFT LCD Display Module 240x284 Home Appliance With ST7789P3-G6 Interface

    RGH Display 1.83 Inch IPS TFT LCD Display Module 240x284 Home Appliance With ST7789P3-G6 Interface


    NO.SymboLeveFunction
    1LEDKLED,cathode
    2GNDGround
    3NCNC
    4SDASPI interface input/output pin.
    5D/Ccommand selection pin in 4-line serial interface
    6SCLThis pin is used to be serial interface clock
    7CsChip selection pin
    8RESETReset signal
    9IOVCC2.8V(typPower supply
    10-11VCC1.8V(typPower supply
    12-13GNDGround
    14-15LEDALED,anode.

    RGH Display 1.83 Inch IPS TFT LCD Display Module 240x284 Home Appliance With ST7789P3-G6 Interface


    FAQ


    1: What are the payment terms?
    A: We usually accept T/T, Paypal, other terms to be negotiated.


    2: What’s the lead time?
    A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).


    3. Do you support custom logo on the LCM?

    A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.


    4. How can I place a sample order?

    A: Pls send us your inquiry, our sales will contact you soon.


    5. What size LCD display can you provide?

    A: 0.96 inch to 21.5 inch TFT LCD display we can provide.


    7. What's your MOQ?

    A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.


    8. What shipping ways do you support?

    A: We can consult with it.
