    LCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial Robots

    Ask Lasest Price
    Brand Name : RGH
    Model Number : RTP55HD011A
    Certification : ISO9001/ISO14001
    Price : Negotiable
    Payment Terms : L/C, T/T,Paypal
    Supply Ability : 3.5kk
    Delivery Time : 3-5weeks
    • Product Details
    • Company Profile

    LCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial Robots

    LCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial RobotsLCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial RobotsLCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial Robots

    NO.SymbolLevelFunction
    1-2LEDA2LED anode
    3-4LEDK2LED cathode
    5-10NCNC
    11GNDGround
    12-13VDDPower setting
    14-15IOVCCA supply voltage tothe digital circuit.Connect to an external power
    supply of 1.65~3.3V.
    16GNDGround
    17RESETInitializethe chip with a low input.Be sure to execute a power-on
    reset after supplying power.
    18GNDGround
    19D3PMIPI DSI differential data pair.
    20D3NMIPI DSI differential data pair.
    21GNDGround
    22D2PMIPI DSI differential data pair.
    23D2NMIPI DSI differential data pair
    24GNDGround
    25CLKPMIPI DSI differential clock pair.
    26CLKNMIPI DSI differential clock pair.
    27GNDGround
    28D1PMIPIDSI differential datapair
    29D1NMIPIDSI differential data pair.
    30GNDGround
    31D0PMIPIDSI differential data pair.
    32D0NMIPI DSI differentialdata pair.
    33-34GNDGround
    35TP-RSTTP-RST
    36TP-INTTP-INT
    37TP-SDATP-SDA
    38TP-SCLTP-SCL
    39TP-GNDTP-GND
    40TP-VDDTP-VDD

    LCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial RobotsLCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial Robots

    LCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial RobotsLCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial RobotsLCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial RobotsLCD TFT Resistive Touchscreen Module SPI Interface 720x1440 For Medical Industrial Robots

    FAQ


    1: What are the payment terms?
    A: We usually accept T/T, Paypal, other terms to be negotiated.


    2: What’s the lead time?
    A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).


    3. Do you support custom logo on the LCM?

    A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.


    4. How can I place a sample order?

    A: Pls send us your inquiry, our sales will contact you soon.


    5. What size LCD display can you provide?

    A: 0.96 inch to 21.5 inch TFT LCD display we can provide.


    7. What's your MOQ?

    A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.


    8. What shipping ways do you support?

    A: We can consult with it.
