IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution

Rongguang Hui Optoelectronics Science and Technology
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution from wholesalers

    Buy cheap IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution from wholesalers
    • Buy cheap IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution from wholesalers
    • Buy cheap IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution from wholesalers
    • Buy cheap IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution from wholesalers
    • Buy cheap IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution from wholesalers

    IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution

    Ask Lasest Price
    Brand Name : RGH
    Model Number : RT32QV002A
    Price : Negotiable
    Certification : ISO9001/ISO14001
    Delivery Time : 3-5weeks
    Payment Terms : L/C, T/T,Paypal
    Supply Ability : 3.5kk
    • Product Details
    • Company Profile

    IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution


    ItemSpecification

    Display mode

    Transmissive TFT

    Part NO.

    RT32QV002A

    Resolution

    240(RGB)*320

    Outline size

    53.60(H) X 76(W) X2.45(T)

    Active area

    48.60(W) X64.80 (H)

    View direction

    ALL o’clock

    Piexl pitch

    240X(RGB)X320

    Interface

    MCU

    Backlight

    6LEDS

    Surface luminance

    420cd/m2

    Driver IC

    ST7789V

    Logic voltage

    2.5V-3.3V

    Operating temperature

    -20℃~70℃

    Storage temperature

    -30℃~80℃
    Weight
    TBD

    IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution


    IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution

    IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution

    NO.SymbolLevelFunction
    1LEDALED,anode
    2-3LEDKLED,cathode
    4TETE
    5RESETThis signal will reset the device and it must be
    applied to properly
    6-13DB7-DB0data bus.
    14GNDGround
    15SDAGround(0V)serial portdata input end
    16RS/SCL-Display data/command selection pin in parallel
    interface
    17RD-Read enable in 8080 MCU parallel interface
    18WR/A0-Write enable in MCU parallel interface
    19CS-Chip selection pin
    20GNDGround
    21VCCsystem voltage
    22IOVCCsystem voltage
    23IM2/IM1
    24GNDGround

    IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 ResolutionIPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution

    IPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 ResolutionIPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 ResolutionIPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 ResolutionIPS TFT LCD HD Display 3.2 Inch Industrial Digital 240*320 Resolution

    FAQ


    1: What are the payment terms?
    A: We usually accept T/T, Paypal, other terms to be negotiated.


    2: What’s the lead time?
    A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).


    3. Do you support custom logo on the LCM?

    A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.


    4. How can I place a sample order?

    A: Pls send us your inquiry, our sales will contact you soon.


    5. What size LCD display can you provide?

    A: 0.96 inch to 21.5 inch TFT LCD display we can provide.


    7. What's your MOQ?

    A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.


    8. What shipping ways do you support?

    A: We can consult with it.
