    TFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED Backlight

    Ask Lasest Price
    Brand Name : RGH
    Model Number : RT20LQ105B
    Certification : ISO9001/ISO14001
    Price : Negotiable
    Payment Terms : L/C, T/T,Paypal
    Supply Ability : 3.5kk
    Delivery Time : 3-5weeks
    • Product Details
    • Company Profile

    TFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED Backlight

    TFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED BacklightTFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED BacklightTFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED Backlight

    NO.SymbolLevelFunction
    1-9DUMMYNo connection.
    10VCOML1UF/25V电容接地
    11VCOMH1UF/25V电容接地
    12GNDVSsGround.
    13DUMMYNo connection.
    14AVDDNo connection.
    15DUMMYNo connection.
    16DUMMYNo connection.
    17DUMMYNo connection.
    18DUMMYNo connection.
    19LEDALED,cathode.
    20DUMMYNo connection.
    21DUMMYNo connection.
    22LEDALED,cathode.
    23GNDVSsGround.
    24VCC2.8V(typ)Power supply.
    25VSYNCH/LFrame synchronizing signal for RGB.
    26HSYNCH/LLine synchronizing signal for RGB.
    27DCLKH/LDot clock signal for RGB.
    28DUMMYNo connection.
    29DUMMYNo connection.
    30-35DB0-DB5H/LData bus.
    36SDAH/LSerial inlout signal.
    37SCLH/LSerial interface clock.
    38CSH/LChip selection.
    39NCNo connection.
    40RESETH/LReset signal.

    TFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED BacklightTFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED Backlight

    TFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED BacklightTFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED BacklightTFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED BacklightTFT LCD Display 2.0 Inch MCU Interface 450cd/M2 ILI9342C LED Backlight

    FAQ


    1: What are the payment terms?
    A: We usually accept T/T, Paypal, other terms to be negotiated.


    2: What’s the lead time?
    A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).


    3. Do you support custom logo on the LCM?

    A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.


    4. How can I place a sample order?

    A: Pls send us your inquiry, our sales will contact you soon.


    5. What size LCD display can you provide?

    A: 0.96 inch to 21.5 inch TFT LCD display we can provide.


    7. What's your MOQ?

    A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.


    8. What shipping ways do you support?

    A: We can consult with it.
