    Smart LCD Display TFT Screen Module RGB 240X320 2.2 Inch

    Ask Lasest Price
    Brand Name : RGH
    Model Number : RT22QV011A
    Certification : ISO9001/ISO14001
    Price : Negotiable
    Payment Terms : L/C, T/T,Paypal
    Supply Ability : 3.5kk
    Delivery Time : 3-5weeeks
    • Product Details
    • Company Profile

    Smart LCD Display TFT Screen Module RGB 240X320 2.2 Inch

    Smart LCD Display TFT Screen Module RGB 240X320 2.2 InchSmart LCD Display TFT Screen Module RGB 240X320 2.2 InchSmart LCD Display TFT Screen Module RGB 240X320 2.2 Inch

    NO.SymbolLevelFunction
    1LEDALED anode
    2LEDK1LED cathode
    3LEDK2LED cathode
    4LEDK3LED cathode
    5LEDK4LED cathode
    6GNDGround
    7NCNC
    8vCCPower setting
    9VCCPower setting
    10NCNC
    11GNDGround
    12CS-Chip selection pin
    13RS-Display data/command selection pin in parallel interface
    14WR-Write enable in MCU parallel interface
    15RDRead enable in 8080 MCU parallel interface
    16RESETThis signal will reset the device and it must be appliedto
    properly
    17GNDGround
    18-25DB0-DB7data bus.
    26GNDGround
    27-34DB8-DB15data bus.
    35GNDGround
    36GNDGround
    37NCNC
    38VCCPower setting
    39IOvCCPower supply for digital interface
    40NCNC

    Smart LCD Display TFT Screen Module RGB 240X320 2.2 InchSmart LCD Display TFT Screen Module RGB 240X320 2.2 Inch

    Smart LCD Display TFT Screen Module RGB 240X320 2.2 InchSmart LCD Display TFT Screen Module RGB 240X320 2.2 InchSmart LCD Display TFT Screen Module RGB 240X320 2.2 InchSmart LCD Display TFT Screen Module RGB 240X320 2.2 Inch

    FAQ


    1: What are the payment terms?
    A: We usually accept T/T, Paypal, other terms to be negotiated.


    2: What’s the lead time?
    A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).


    3. Do you support custom logo on the LCM?

    A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.


    4. How can I place a sample order?

    A: Pls send us your inquiry, our sales will contact you soon.


    5. What size LCD display can you provide?

    A: 0.96 inch to 21.5 inch TFT LCD display we can provide.


    7. What's your MOQ?

    A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.


    8. What shipping ways do you support?

    A: We can consult with it.
