7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

Rongguang Hui Optoelectronics Science and Technology
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600 from wholesalers

    Buy cheap 7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600 from wholesalers
    • Buy cheap 7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600 from wholesalers
    • Buy cheap 7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600 from wholesalers
    • Buy cheap 7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600 from wholesalers
    • Buy cheap 7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600 from wholesalers
    • Buy cheap 7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600 from wholesalers

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    Ask Lasest Price
    Brand Name : RGH
    Model Number : RT70HD005A
    Price : Negotiable
    Payment Terms : L/C, T/T,Paypal
    Supply Ability : 3.5kk
    Delivery Time : 3-5weeks
    Certification : ISO9001/ISO14001
    • Product Details
    • Company Profile

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    NO.SymbolLevelFunction
    1VCOMCommon Voltage
    2VDDPower setting
    3VDDPower setting
    4NCNC
    5RESETRESET.PIN
    6STBYB(3.3V
    )
    Standby mode,usually pull high STBYB=1,normal operation
    STBYB=0,timing controller,sourcedriverwill shut down,al
    output high red shift
    7GNDGround
    8RXIN0--LVDS differential data input
    9RXIN0++LVDS differential data input
    10GNDGround
    11RXIN1--LVDS diffe rential datainput
    12RXIN1++LVDS differential data input
    13GNDGround
    14RXIN2--LVDS diffe rential data input
    15RXIN2++LVDS differential data input
    16GNDGround
    17RXCLKIN--LVDS differential CLOCK input
    18RXCLKIN+-LVDS differential CLOCK input
    19GNDGround
    20RXIN3--LVDS differential data input
    21RXIN3++LVDS differential datainput
    22GNDGround
    23NCNC
    24NCNC
    25GNDGround
    26NCNC
    27DIMO(3.3V)Backlit CABC controller signa output
    28SELB(1.8V)6bit/8bit mode selection(Note 1)LVBIT=L",6 bits.LVBIT="H",
    8 bits. (the default)
    29AVDDPower for Analog circuit
    30GNDGround
    31LEDKLED power cathode
    32LEDKLED power cathode
    33UR(1.8V)Horizontal reversalSHLR=L",leftshift SHLR="H",nghtshift:
    34U/D(1.8v)Vertical Tnversion-UPDNB="L",STVi outputs the vertical start
    pulse and UD pin output "H"UPDNB="H",STV2 outputs the
    vertical start pulse and up pin output
    35VGLGATE OFF Voltage
    36-37GNDGround
    38VGHGate On Voltage
    39-40LEDALED power anode

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    7 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x6007 Inch Horizontal TFT And IPS Display Module HD LCD Screen 1024x600

    FAQ


    1: What are the payment terms?
    A: We usually accept T/T, Paypal, other terms to be negotiated.


    2: What’s the lead time?
    A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).


    3. Do you support custom logo on the LCM?

    A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.


    4. How can I place a sample order?

    A: Pls send us your inquiry, our sales will contact you soon.


    5. What size LCD display can you provide?

    A: 0.96 inch to 21.5 inch TFT LCD display we can provide.


    7. What's your MOQ?

    A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.


    8. What shipping ways do you support?

    A: We can consult with it.
