    IPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd Display

    Ask Lasest Price
    Brand Name : RGH
    Model Number : RT235QV007A
    Certification : ISO9001/ISO14001
    Price : Negotiable
    Payment Terms : L/C, T/T,Paypal
    Supply Ability : 3.5kk
    Delivery Time : 3-5weeks
    • Product Details
    • Company Profile

    IPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd Display

    IPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd DisplayIPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd DisplayIPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd Display

    NO.SymbolLevelFunction
    1LEDAlLED power anode
    2LEDKLED power cathode
    3GNDGround
    4RESETReset pin
    5VSFrame synchronizing signal for RGB interface
    operation
    6HSLine synchronizing signal for RGB interface
    operation
    7DCLKDot clock signal for RGB interface operation
    8DEData enable signal for RGB interface operation
    9GNDGround
    10-14R4-R0data bus
    15-20G5-G0data bus
    21-25B4-B0data bus
    26IOVCCPower setting
    27SDISerial data inputloutput bidirectional pin for SPI
    Interface.
    28SDLSerial clock input for SPI interface.
    29CSchip select signal
    30VCCPower setting

    IPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd DisplayIPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd Display

    IPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd DisplayIPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd DisplayIPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd DisplayIPS TFT LCD Display 2.35 Inch Operating Temperature -20℃~70℃ Brightness 700cd/M2 Lcd Display

    FAQ


    1: What are the payment terms?
    A: We usually accept T/T, Paypal, other terms to be negotiated.


    2: What’s the lead time?
    A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).


    3. Do you support custom logo on the CTP?

    A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.


    4. How can I place a sample order?

    A: Pls send us your inquiry, our sales will contact you soon.


    5. What size LCD display can you provide?

    A: 0.96 inch to 20 inch TFT LCD display we can provide.


    7. What's your MOQ?

    A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.


    8. What shipping ways do you support?

    A: We can consult with it.
