Product Description:
Featuring a black and white display, this E-paper display is
perfect for applications where high contrast and readability are
paramount. This E-paper display offers a clear, easy-to-read
display that is ideal for a range of applications, including
e-readers, smartwatches, and digital signage.
The E-ink Epaper Display is the perfect choice for applications
where touch screen functionality is not required. Its simple,
intuitive interface allows for easy integration into a wide range
of devices, making it ideal for use in a variety of applications.
With an outline dimension of 36.3*71.8*1.14 and an active area of
30.704*60.088, this E-paper display is both compact and versatile,
making it an ideal solution for a wide range of applications.
The E-ink Epaper Display is perfect for creating high-quality,
low-power displays that are both easy to read and easy to use.
Whether you're looking for a display for your e-reader or a digital
signage solution, this E-paper display is the perfect choice.
Features:
- Product Name: E-ink Epaper Display
- Outline Dimension: 36.3*71.8*1.14
- Interface type: SPI
- Display Color: Black And White
- PIN number: 24pins
- Touch Screen: No
| No. | Name | VO | Description | Remark |
| 1 | NC | | Do not connect with other NC pins | |
| 2 | GDR | 0 | N-Channel MOSFET Gate Drive Control | |
| 3 | RESE | I | Current Sense Input for the Control Loop | |
| 4 | NC | / | Do notconnect with other NC pins | |
| 5 | VDHR | C | Positive source drivervoltage for Source | |
| 6 | TSCL | 0 | FC Interface to digital temperature sensor Clock pin | |
| 7 | TSDA | UO | FC Interface to digital temperature sensor Data pin | |
| 8 | BS | | Bus Interface selection pin | Note 5-4 |
| 9 | BUSYN | 0 | Busy state output pin | Note 5-3 |
| 10 | RSTN | | Reset signal input.Active Low. | |
| 11 | N/C | | Data /Command control pin | Note 5-2 |
| 12 | CS# | | Chip select input pin | Note 5-1 |
| 13 | SCL | | Serial Clock pin (SPl) | |
| 14 | SCA | | Seria Data pin (SPI) | |
| 15 | VDD | P | Power Supply for interface logic pins. | |
| 16 | VDD | P | Power Supply for the chip | |
| 17 | VSs | P | Ground | |
| 18 | VDDD | C | Core logic powerpin
VDDD can be regulated intemally fromVDD.A capacitor should
be connected between VDD and VSS under all circumstances | |
| 19 | VPP | P | Power Supply for OTP Programming | |
| 20 | VSH | C | Positive Source driving voltage | |
| 21 | VGH | C | Positive Gate driving voltage | |
| 22 | VSL | C | Negative Source drivingvoltage | |
| 23 | VGL | C | Negative Gate driving voltage | |
| 24 | VCOM | C | VCOM driving voltage | |
Applications:
The RGH SE0266N01-A0 E-paper display is designed for a variety of
product application occasions and scenarios. It can be used in
e-readers, electronic shelf labels, smart wearables, smart home
devices, and many more. The E-paper display technology used in this
product provides an excellent reading experience with a paper-like
display that is easy on the eyes.
The E-paper display is perfect for e-readers, where users can read
books, magazines, articles, and other documents. The E-paper
display provides a comfortable reading experience, even in bright
sunlight. The RGH SE0266N01-A0 E-paper display can also be used in
electronic shelf labels, where it can be easily updated with new
prices and product information.
The RGH SE0266N01-A0 E-paper display can be used in smart wearables
like smartwatches and fitness bands. The E-paper display provides a
low-power display that can show notifications, time, and other
information. The E-paper display is also perfect for smart home
devices like smart thermostats and smart doorbells.
The RGH SE0266N01-A0 E-paper display has an interface type of SPI
and a PIN number of 24pins. This makes it easy to integrate with
other electronic devices. The E-paper display can be easily
connected to a microcontroller or other embedded systems.
Support and Services:
Our E-ink Epaper Display product technical support and services
include:
- Product installation and setup assistance
- Troubleshooting and problem-solving
- Software and firmware updates
- Product maintenance and repair services
- Technical documentation and resources
- Product training and education
- Customization services for specific product needs
We are committed to providing excellent customer service and
technical support for our E-ink Epaper Display product.
FAQ:
Q: What is the brand name of this E-ink Epaper Display?
A: The brand name of this E-ink Epaper Display is RGH.
Q: What is the model number of this E-ink Epaper Display?
A: The model number of this E-ink Epaper Display is SE0266N01-A0.
Q: Where is this E-ink Epaper Display made?
A: This E-ink Epaper Display is made in Shenzhen,China.
Q: What is the resolution of this E-ink Epaper Display?
A: The resolution of this E-ink Epaper Display is 200x200 pixels.
Q: Is this E-ink Epaper Display compatible with Raspberry Pi?
A: Yes, this E-ink Epaper Display is compatible with Raspberry Pi.
