OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

Rongguang Hui Optoelectronics Science and Technology
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD from wholesalers

    Buy cheap OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD from wholesalers
    • Buy cheap OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD from wholesalers
    • Buy cheap OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD from wholesalers
    • Buy cheap OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD from wholesalers
    • Buy cheap OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD from wholesalers

    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

    Ask Lasest Price
    Brand Name : RGH
    Model Number : RT20QV227A
    Price : Negotiable
    Certification : ISO9001/ISO14001
    Payment Terms : L/C, T/T,Paypal
    Supply Ability : 3.5kk
    Delivery Time : 3-5weeks
    • Product Details
    • Company Profile

    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

    ItemSpecification

    Size:

    2.0inch

    Display mode

    Transmissive TFT

    Part NO.

    RT20QV227A

    Resolution

    240*320

    Outline size

    36.05(H)*51.80(V)*2.45(T)

    Active area

    30.6(W)*40.8(H)

    View direction

    ALL

    Piexl pitch

    240(RGB)*320

    Interface

    MCU 8bit

    Backlight

    3LEDS

    Surface luminance

    500cd/m2

    Logic voltage

    2.5V-3.3V

    Operating temperature

    -10℃~60℃

    Storage temperature

    -20℃~70℃

    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

    NO.SymbolLevelFunction
    1LEDALED,anode.
    2LEDKLED,cathode.
    3-4NCNC
    5IOvCC1.8V/2.8VPower supply
    6VCC2.8V(typ)Power supply
    7-14DB7-DB0data bus
    15RD-Read enable in 8080 MCU parallel interface
    16WR-Write enable in MCU parallel interface
    17RS-Display data/command selection pin inparallel interface
    18CS-Chip selection pin
    19TE-Tearing effect signal is used to synchronize MCU to frame memory
    20RESET-This signal will reset the device and it must be applied to properly
    21-22GNDGND

    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCDOEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD


    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

    OEM MCU 8bit 2" TFT Display SPI 240x320 Resolution For Differentiated LCD

    FAQ


    1: What are the payment terms?
    A: We usually accept T/T, Paypal, other terms to be negotiated.


    2: What’s the lead time?
    A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).


    3. Do you support custom logo on the LCM?

    A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.


    4. How can I place a sample order?

    A: Pls send us your inquiry, our sales will contact you soon.


    5. What size LCD display can you provide?

    A: 0.96 inch to 21.5 inch TFT LCD display we can provide.


    7. What's your MOQ?

    A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.


    8. What shipping ways do you support?

    A: We can consult with it.
