Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

Rongguang Hui Optoelectronics Science and Technology
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM from wholesalers

    Buy cheap Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM from wholesalers
    • Buy cheap Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM from wholesalers
    • Buy cheap Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM from wholesalers
    • Buy cheap Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM from wholesalers
    • Buy cheap Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM from wholesalers

    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

    Ask Lasest Price
    Brand Name : RGH
    Model Number : RT23WV005A
    Price : Negotiable
    Certification : ISO9001/ISO14001
    Payment Terms : L/C, T/T,Paypal
    Supply Ability : 3.5kk
    Delivery Time : 3-5weeks
    • Product Details
    • Company Profile

    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

    ItemSpecification

    Size

    2.3inch

    Display mode

    Transmissive TFT

    Part NO.

    RT23WV005A

    Resolution

    480*320

    Outline size

    50.90 (W) X45.80(H) X2.3(T)

    Active area

    46.80(W) X35.10 (H)

    View direction

    ALL o’clock

    Piexl pitch

    480(RGB)X360

    Interface

    MIPI

    Backlight

    4LEDS

    Surface luminance

    450cd/m2

    Logic voltage

    2.5V-3.3V

    Operating temperature

    -20℃~70℃

    Storage temperature

    -30℃~80℃

    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

    NO.SymbolLevelFunction
    1GNDGround
    2IOvCC1.8VPower setting
    3GNDGround
    4GNDGround
    5LEDKLED power cathode
    6LEDALED power anode
    7GNDGround
    8GNDGround
    9GNDGround
    10GNDGround
    11GNDGround
    12GNDGround
    13D1NMIPI Data pin Positive
    14D1PMIPI Data pin Positive
    15D0NMIPI Data pin Positive
    16D0PMIPI Data pin Positive
    17CKNMipiclock signal
    18CKPMipi clock signal
    19GNDGround
    20RESETRESET PIN
    21TETE
    22GNDGround
    23VCC2.8VPower setting
    24VCC2.8VPower setting
    25GNDGround

    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEMHandheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM


    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

    Handheld Digital Full HD IPS TFT LCD Display 480x360 2.3 Inch OEM

    FAQ


    1: What are the payment terms?
    A: We usually accept T/T, Paypal, other terms to be negotiated.


    2: What’s the lead time?
    A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).


    3. Do you support custom logo on the LCM?

    A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.


    4. How can I place a sample order?

    A: Pls send us your inquiry, our sales will contact you soon.


    5. What size LCD display can you provide?

    A: 0.96 inch to 21.5 inch TFT LCD display we can provide.


    7. What's your MOQ?

    A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.


    8. What shipping ways do you support?

    A: We can consult with it.
