RGH 6.5inch Lcd Touch Display 720(RGB)X1600 With 16 leds Backlights
Product Specification
| Size | 6.5inch |
| Resolution | 720(RGB)X1600 |
| Viewing Direction | ALL o’clock |
| Operating temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| LCM Outline | 73.23 (H) X161.40(V) X2.76(T) mm |
| Driving IC | FT8057M |
| Luminance | 350CD/M2 |
Interface Pin Definition
| NO. | Symbol | Level | Function |
| 1 | LEDK | | LED power cathode |
| 2 | LEDA | | LED power anode |
| 3-4 | NC | | NC |
| 5 | GND | | Ground |
| 6 | IOVCC | | Power Supply for I/O System. |
| 7 | VCC | | Power setting |
| 8 | TP-VDD | | TP-VDD |
| 9 | TP-SDA | | TP-SDA |
| 10 | TP-SCL | | TP-SCL |
| 11 | TP-RST | | TP-RST |
| 12 | TP-INT | | TP-INT |
| 13 | NC | | NC |
| 14 | TE | | TE PIN |
| 15 | RESET | | -The external reset input |
| 16 | GND | | Ground |
| 17 | DN3 | | MIPI Data pin Positive |
| 18 | DP3 | | MIPI Data pin Positive |
| 19 | GND | | Ground |
| 20 | DN2 | | MIPI Datapin Positive |
| 21 | DP2 | | MIPI Data pin Positive |
| 22 | GND | | Ground |
| 23 | CLKN | | Mipi dlock signal |
| 24 | CLKP | | Mipi clock signal |
| 25 | GND | | Ground |
| 26 | DN1 | | MIPI Data pin Positive |
| 27 | DP1 | | MIPI Data pin Positive |
| 28 | GND | | Ground |
| 29 | DN0 | | MIPI Data pin Positive |
| 30 | DP0 | | MIPI Data pin Positive |
External Dimensions
About this item
6.5-inch LCD Touch Display (RGB) 720x1600 with 16 LEDs Backlights
This high-quality 6.5-inch LCD touch display offers stunning RGB
colors with a resolution of 720x1600 pixels. Equipped with 16 LED
backlights for enhanced brightness and clarity, it is perfect for
various applications, including mobile devices, embedded systems,
and other display-centric projects.
Brand: RGH
Place of Origin: Shenzhen, China
Certification: ISO 9001, ISO 14001
Model Number: RTP65HD002A
Features: High resolution, touch-sensitive, 16 LED backlights, RGB
display
What products can be applied?
Smartphones and Tablets: Ideal for smaller devices or those with
compact designs that require high-quality displays but still need
to be portable.
Wearables (Smartwatches, Fitness Trackers): The screen size is
suitable for wearable devices, offering touch functionality and
high resolution in a compact form.
Embedded Systems: This display can be used in embedded
applications, such as industrial equipment or home automation
devices, where a user interface is needed.
Point of Sale (POS) Systems: The 6.5-inch size is a good fit for
POS terminals, providing a responsive touch interface and clear
display for transaction details.
Automotive Dashboards: This screen can be integrated into car
dashboards or infotainment systems, offering high-definition
visuals for navigation, controls, and media playback.
Gaming Devices: Handheld gaming consoles or portable gaming devices
can benefit from this size, offering clear visuals and an immersive
experience.
Consumer Electronics: Devices like smart home controllers, personal
assistants, or other consumer gadgets that need an interactive
display.
Medical Devices: Portable medical instruments that require user
interaction can utilize this screen, such as blood pressure
monitors, glucose meters, or diagnostic tools.
Kiosk Systems: Interactive kiosks, such as those found in retail,
ticketing, or information booths, can benefit from the compact size
while maintaining good visibility.
